DECT-6012-V | Specific

产品特色

Intel^® Core™ i Fan-less Medical Box PC
7^th generation Intel^® kabylake-U Core™ i Low power processor
Dual HDMI display output
Fan-free & Cable-free design
Comply with IEC60601-1-2

产品描述

The DTEC-6012-V / DTEC-6014-V builds on Intel^® Core™ i3-7100U / i5-7300U low power processor technologies that can support DDR4 memory. Dual HDMI display output, one M.2 socket . DTEC-6012-V / DTEC-6014-V is an ideal platform with rich I/O and high resolution for telemedicine and comply with IEC60601-1-2 makes it a perfect solution to control medical equipment.control medical equipment.

规格

Processor	Intel^® Core™ i3-7100U,QC, 2.30 GHz, 15 W – Intel^® Core™ i5-7300U, QC, 2.40 GHz, 15 W
BIOS	AMI uEFI BIOS
Memoy	SODIMM x 1, max. 16GB, DDR4 2133 non-ECC
Storage	1x SATA III port
Expansion Interface	M.2 Key E (Supports 2230) – Mini PCIe (half size)
Serial Port	RS232 DB-9 connector x2
USB	USB3.0 x4
Audio	Audio Jack x 2: Line-in,Mic-in & Line-out
Ethernet	Gigabit LAN x1
Display	2x HDMI : Supports max resolution up to 4Kx2K@30Hz
Power Input	DC 12V input with Power Adapter
Operation Temperature	0°C ~ 40°C
Storage Temperature	– 40°C ~ 80°C
Dimension	152(W) x 237.4(H) x 44(D) mm
Weight	1.45 kg
