| Processor | Socket LGA1151 for Intel 10th Comet Lake Core™ i7/i5/i3®, up to 35W |
| Memory | 2x DDR4 SO-DIMM 2400/ 2666 memory up to 64GB |
| Storage | – 1x M.2 2280 SSD – 2x 2.5″ SSD |
| OS Support | Windows 10, Linux |
| USB | USB3.0 x6 |
| Serial port | RJ45 connector x1 |
| Ethernet | Gigabit LAN x4 |
| Display | HDMI® x1, DP x1 |
| Audio | Audio Jack x1: Combo connector |
| PCIe slot | N/A |
| Optional | M.2 Bluetooth & Wifi module |
| Power input | 2.5mm DC-Jack AT 12v Power connector x1 |
| Power limit | 120W(12V/ 10A) |
| Power supply | AC to DC Adapter |
| Dimension(Wx Dx H) | 290 x 200 x 44.45 mm |
