Compact and Projective Capacitive Touch HMI with Wide Temperature and Voltage Support Powered by NXP i.MX 6 Series Family


  • RISC based Fan-less and Cable-less Touch PPC
  • i.MX6 Cortex A9 1GHz
  • Built-in DDR3 2GB, 8GB eMMC
  • 10.1″ Industrial panel
  • Wide Power input from DC12~24V
  • Gigabit Ethernet * 1
  • RS-232/422/485 * 1
  • CAN * 1

– External HDMI® monitor via one HDMI® output port

– Ideal PIP solution to integrate external video signal and computing on COMBO 10.1″ HMI


– Slim, Fan-less and Cable-less

– Panel & VESA mount support

– Removable SD cover

– 1x Full-size mPCIe socket for WIFI

– 1x Half-size mPCIe socket for mSATA

– Android, Yocto Linux + QT

– Low Impact on OS Migration

  • P-CAP multi-touch screen
  • Low Power Consumption
  • Replace Intel Atom Processor
  • Longevity Support (10~15 years)


In IPC market, a robust and highly reliable Panel PC system is a must to ensure non-stop and stable operation on production line. Featuring cost effective and power efficiency, COMBO Series is an ideal HMI in factory automation, food and beverage industry, data collecting equipment environments.
