| CPU |
Intel® Core™ i7-4770S Processor (4 x 3.10 GHz / 3.90 GHz, 8 MB SmartCache, 65 W)
Intel® Celeron® Processor G1820TE (2 x 2.20 GHz, 2 MB SmartCache, 35 W)
Intel® Core™ i3-4360 Processor (2 x 3.70 GHz, 4 MB SmartCache, 54 W)
Intel® Core™ i3-4350T Processor (2 x 3.10 GHz, 4 MB SmartCache, 35 W)
Intel® Core™ i3-4340TE Processor (2 x 2.60 GHz, 4 MB SmartCache, 35 W)
Intel® Core™ i3-4330TE Processor (2 x 2.40 GHz, 4 MB SmartCache, 35 W)
Intel® Core™ i3-4330 Processor (2 x 3.50 GHz, 4 MB SmartCache, 54 W)
Intel® Core™ i5-4590T Processor (4 x 2.00 GHz / 3.00 GHz, 6 MB SmartCache, 35 W)
Intel® Core™ i5-4590S Processor (4 x 3.00 GHz / 3.70 GHz, 6 MB SmartCache, 65 W)
Intel® Core™ i5-4570TE Processor (2 x 2.70 GHz / 3.30 GHz, 4 MB SmartCache, 35 W)
Intel® Core™ i5-4570S Processor (4 x 2.90 GHz / 3.60 GHz, 6 MB SmartCache, 65 W)
Intel® Core™ i7-4790S Processor (4 x 3.20 GHz / 4.00 GHz, 8 MB SmartCache, 65 W)
Intel® Core™ i7-4770TE Processor (4 x 2.30 GHz / 3.30 GHz, 8 MB SmartCache, 45 W)
Intel® Celeron® Processor G1820 (2 x 2.70 GHz, 2 MB SmartCache, 53 W) |
| Display Interface |
DVI (1920 x 1200), HDMI (4096 x 2304), VGA (1920×1200) |
| Storage |
2x SATA II (3.0Gb/s), 2x SATA III (6.0Gb/s), 1x (CFEX) |
| Network |
2x GbE Realtek RTL8111D |
| Bus Interface |
1x PCI-Express x16 slot, 2x PCIe x1 on golden finger, LPC support, SMBus |
| Serial Interface |
3x RS232, 1x RS232/422/485 |
| USB |
2x USB 3.0, 8x USB 2.0 |
| Audio |
Intel® HD Audio, Realtek ALC892 |
| Security |
TPM Module |
| Miscellaneous |
2x PS/2 via pin header, GPIO 8bit,Watchdog Timer,HW monitoring temperature & voltage |
| Firmware |
AMI UEFI BIOS (SPI ROM) |
| Power Requirement |
ACPI 3.0 / APM 1.2 |
| Power from W |
ATX 24-pin power input |
| Operating Temperature |
0°C – 60°C |
| Storage Temperature |
-20°C~80°C |
| Dimensions |
170×170 mm |
| Technology |
x86 |
| Format |
Mini-ITX |
| Chipset |
Intel® H81 |
| DRAM |
Up to 16 GB DDR3 SDRAM non ECC |
