COM-B880VG2 是Intel® Comet Lake-S platform COM-HPC® Client, Size C 模块。 COM-HPC® Client Formfactor 支持更多 I/O 接口和桌面级 CPU 的能力，以满足更广泛的计算需求应用。 与移动解决方案相比，模块上的桌面 CPU 可为客户提供更高的计算能力，但成本更低。 PCOM-B880VG2 通过不同的PCH SKU（Q470E/W480E）同时支持ECC和Non-ECC DDR4，可以适应不同的应用。 该模块提供一个 PCIex16、四个 USB 3.2 Gen2、 两个 SATA III、PCIe 存储和多达 20 个 PCIe x1 通道。
| CPU and General | |||||
| Form Factor | COM HPC Client, Size C | ||||
| Xeon series | Xeon W-1250E, 6C/12T, 3.5 GHz, 12 MB, 80W | ||||
| Xeon W-1290TE, 10C/20T, 1.8 GHz, 20 MB, 35W | |||||
| Xeon W-1270TE, 8C/16T, 2.0 GHz, 16 MB, 35W | |||||
| Xeon W-1250TE, 6C/12T, 2.4 GHz, 12 MB, 35W | |||||
| Core i series | i9-10900TE, 10C/20T, 1.8 GHz, 20 MB, 35W | ||||
| i7-10700TE, 8C/16T, 2.0 GHz, 16 MB, 35W | |||||
| i5-10500E, 6C/12T, 3.1 GHz, 12 MB, 65W | |||||
| i5-10500TE, 6C/12T, 2.3 GHz, 12 MB, 35W | |||||
| i3-10100E, 4C/8T, 3.2 GHz, 6 MB, 65W | |||||
| i3-10100TE, 4C/8T, 2.3 GHz, 6 MB, 35W | |||||
| Pentium/Celeron series | Pentium G6400E, 2C/4T, 3.8 GHz, 4 MB, 65W | ||||
| Pentium G6400TE, 2C/4T, 3.2 GHz, 4 MB, 35W | |||||
| Celeron G5900E, 2C/2T, 3.2 GHz, 2 MB, 65W | |||||
| Celeron G5900TE, 2C/2T, 3.0 GHz, 2 MB, 35W | |||||
| I/O Interface | |||||
| SATA | 2 x SATA III | ||||
| NVME | 2x PCIe NVME Gen3 x4, with Intel® RST | ||||
| USB | 4x USB 3.2 Gen2 8x USB 2.0 |
||||
| Ethernet | Intel® I225LM | ||||
| AUDIO | HDA | ||||
| Serial I/O | GPIO | 12 bit GPIO (default 6 input / 6 output) | |||
| I2C | Baud Rate : 400KHz | ||||
| SMBus | Baud Rate : 100KHz | ||||
| eSPI | |||||
| UART | TX/RX signal only | ||||
| PEG | 1x Gen3 x16 (Group 1) (Bifucation Support: 2 x8, or 1×8 + 2×4) |
||||
| PCI Express Gen3 | 8x Gen3 x1 (Group 0 Low) 2x Gen3 x4 (Group 0 High) 1x Gen3 x4 (Group 2, #32 ~ #35) |
||||
| Display | Default | Options | Resolution | ||
| eDP 1.4 | 4096 x 2304@60Hz | ||||
| DDI 1, 2, & 3 | DP 1.4 | 4096 x 2304@60Hz | |||
| HDMI 2.0a | 4096 x 2160@60Hz | ||||
| HDMI 1.4 | 4096 x 2160@60Hz | ||||
| Security | TPM 2.0 | ||||
| MECHANICAL & ENVIRONMENT | |||||
| Dimension | 160mm x 120mm | ||||
| Power DC IN | Normal: +12V DC AT/ATX mode |
||||
| Storage Temperature | 0°C to 60°C | ||||
| Operating Temperature | 0°C to 60°C | ||||
| Certification | Contact us | ||||
| MTBF | TBD | ||||
| Vibration | TBD | ||||
| OS | Windows 10 Ubuntu, CentOS |
||||
| Product | Ordering P/N | Status |
| PCOM-B880VG2-W480E | AB1-3L36 | Available |
| PCOM-B880VG2-Q470E | AB1-3L35 | Available |
| Accessory | Ordering P/N | Status |
| Cooler 125W | B9971030 | Available |
| Cooler 80W | B9971060 | Available |
| Cooler 35W | B8304610 | Available |
| PCOM-C880 (ATX carrier board) |
AB1-3L34Z | In Development |
