MPI-815H

150W 1U ATX power supply with active PFC

产品特色

  • 1U ATX power supply
  • Full-range input
  • Max. +5V standby output is 14A
  • Thermal protection
  • +5V standby & remote On/Off

规格

Specifications
Input Voltage 90V ~ 264V AC, full range
Input Frequency 47 ~ 63 Hz
Input Current 6A@115V, 3A@230V
Efficiency > 75%
Holdup Time 16 ms at full load
Over Voltage Protection +5V: 5.7 ~ 6.5V; +3.3V: 3.9 ~ 4.3V; +12V: 13.6 ~ 15
Over Power/ Load Protection Output power over 110% ~ 150%
MTBF >130,000 hrs
EMI & Safety Approval UL
Temperature/ Humidity Operating: 0oC ~ 40oC, 20% ~ 90%RH Storage: -20oC ~ 60oC, 5% ~ 95%RH
Dimension (WxDxH) 198 x 93 x 40.5 mm; 7.8” x 3.66” x 1.6”

订购指南

Ordering Guide
MPI-815H 150W fanless, 1U, ATX power supply
